Intelligent fresh vegetable packing machine

Application:

Horizontal Flow Packing Machine ( Upgraded Version ) is suitable for packaging soft, strip and unorganized objects into pillow bag or gusseted bag. Like towels, tissues, noodles, egg rolls, sausages, ice-lollies, soft candies, fresh fruits, fresh vegetable without tray etc.

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Get Price Send Email

Features:

* For Stable Performance: Three servo controller, upgradable PLC system, self-failure diagnosis.

* For Easy Operation: Touch screen monitor, independant temperature PID controller.

* For Adapability: one set of machine can be applicated to different kind of product via optional devices, such as air-filling device, feeding line, date printer, etc.

Application:

Suitable for soft,several product one bag,viscous product. such as leaf vegetable, noodle, disposable tableware (Plastic Fork Spoon Tissue), chopsticks, toothbrushes & toothpaste, candles, agarbatti, incense sticks, gloves, multi straws, colorful crayons, pen.

Specification:

Model	VT-110X	VT-160X	VT-210X	VT-280X	VT-330X
Film Width	Max.240mm	Max.340mm	Max.440mm	Max.580mm	Max.680mm
Bag Length	65-400mm	60-400mm	95-500mm	150-550mm	150-550mm
Bag Width	30-110mm	30-160mm	50-210mm	60-280mm	80-330mm
Products High	Max.55mm	Max.55mm	Max.85mm	Max.110mm	Max.110mm
Film Roll Diameter	Max.380mm	Max.380mm	Max.380mm	Max.380mm	Max.380mm
Packing Speed	30-200bag/min	30-200bag/min	30-120bag/min	20-120bag/min	20-100bag/min
Power	220V 50/60Hz 2.6KW	220V 50/60Hz 2.6KW	220V 50/60Hz 3KW	220V 50/60Hz 3.5KW	220V 50/60Hz 3.5KW
Machine Size (LWH)mm	38007101450	39007851450	39008601450	40009601550	400010001550
Machine Weight	About 500kg	About 580kg	About 650kg	About 700kg	About 750kg
